The Chevy Equinox is a popular crossover SUV that was first introduced in 2005. It is now in its second generation and continues to be a favorite choice for drivers all over the country. The Chevy Equinox comes with a 1.5L turbo engine. One of the questions that often comes up about the Chevy Equinox is what is the Engine Oil Capacity? This article will answer that question and provide additional information about the Chevy Equinox Engine Oil Capacity.
If your vehicle is still under warranty, Chevrolet advises drivers to take their car to an Authorized Chevrolet Dealer for an engine oil change.
Chevrolet Equinox Engine Oil Capacity Chart For All Generations
2005 2006 2007 2008 2009 Chevy Equinox Engine Oil Capacity
The first-generation 2005 – 2009 Chevy Equinox holds 4.5 quarts for a 3.4l engine and 5.5 quarts for a 3.6l engine.
2005 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2005 Chevy Equinox 3.4L LNJ | 4.5 qt (4.3 l) | 5W-30, 10W-30 |
2006 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2006 Chevy Equinox 3.4L LNJ | 4.5 qt (4.3 l) | 5W-30, 10W-30 |
2007 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2007 Chevy Equinox 3.4L LNJ | 4.5 qt (4.3 l) | 5W-30, 0W-30 |
2008 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2008 Chevy Equinox 3.4L LNJ | 4.5 qt (4.3 l) | 5W-30, 0W-30 |
| 2008 Chevy Equinox 3.6L | 5.5 qt (5.2 l) | 5W-30, 0W-30 |
2009 Chevrolet Equinox Engine Oil Capacity and oil type
The 3.4L V6 engine was standard on the 2008 Chevy Equinox, but a 3.6L V6 engine upgrade was available. The regular motor will have a motor Engine Oil Capacity of 4.5 liters, but the improved one will need 5.4 liters to completely fill up. Both types of engines require synthetic 5W-30 motor oil to function properly. To remove the drain plug on these cars, you’ll need a 15mm diameter head and 24 ft-lbs of torque; in order to remove it, you’ll first need to loosen it with a wrench or an adjustable spanner (for v8 models only).
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2009 Chevy Equinox 3.4L LNJ | 4.5 qt (4.3 l) | 5W-30, 0W-30 |
| 2009 Chevy Equinox 3.6L | 5.5 qt (5.2 l) | 5W-30, 0W-30 |
2005 – 2009 Chevy Equinox Engine Oil Change
2010 2011 2012 2013 2014 2015 2016 2017 Chevy Equinox Engine Oil Capacity
The second-generation Chevy Equinox requires 6 quarts for a 3l engine and 5 quarts of oil for a 2.4l engine.
2010 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2010 Chevy Equinox 3.0L LF1 | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2010 Chevy Equinox 2.4L LAF | 5 qt (4.7 l) | 5W-30, 0W-30 |
2011 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2011 Chevy Equinox 3.0L LFW Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2011 Chevy Equinox 2.4L LAF | 5 qt (4.7 l) | 5W-30, 0W-30 |
2012 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2012 Chevy Equinox 3.0L LFW | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2012 Chevy Equinox 3.0L LFW Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2012 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2012 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2013 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2013 Chevy Equinox 3.0L LFX | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2013 Chevy Equinox 3.0L LFX Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2013 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2013 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2014 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2014 Chevy Equinox 3.0L LFX | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2014 Chevy Equinox 3.0L LFX Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2014 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2014 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2015 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2015 Chevy Equinox 3.0L LFX | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2015 Chevy Equinox 3.0L LFX Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2015 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2015 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2016 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2016 Chevy Equinox 3.0L LFX | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2016 Chevy Equinox 3.0L LFX Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2016 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2016 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2017 Chevrolet Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2017 Chevy Equinox 3.0L LFX | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2017 Chevy Equinox 3.0L LFX Flex | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2017 Chevy Equinox 2.4L LEA | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2017 Chevy Equinox 2.4L LEA Flex | 5 qt (4.7 l) | 5W-30, 0W-30 |
2010 – 2017 Chevy Equinox Engine Oil Change
2018 2019 2020 2021 2022 2023 Chevy Equinox Engine Oil Capacity
The third-generation Chevy Equinox holds between 4.2 quarts and 6 quarts of oil depending on the engine size.
2018 Chevy Equinox Engine Oil Capacity and oil type
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2018 AWD Chevy Equinox 2.0L LTG Turbo | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2018 FWD Chevy Equinox 2.0L LTG Turbo | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2018 Chevy Equinox 1.6L LH7 Diesel Turbo | 5.3 qt (5 l) | 5W-30, 0W-40 |
| 2018 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2018 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
2019 Chevy Equinox Engine Oil Capacity and oil type
The 2.0 Chevy Equinox takes 5 and 6 quarts of oil for FWD and AWD versions. For a 1.5 engine, Equinox holds from 4.2 to 5.3 quarts of oil with a filter change.
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2019 AWD Chevy Equinox 2.0L LTG Turbo | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2019 FWD Chevy Equinox 2.0L LTG Turbo | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2019 Chevy Equinox 1.6L LH7 Diesel Turbo | 5.3 qt (5 l) | 5W-30, 0W-40 |
| 2019 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2019 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
2020 Chevy Equinox Engine Oil Capacity and oil type
The 2.0 Chevy Equinox takes 5 and 6 quarts of oil for FWD and AWD versions. For a 1.5 engine, Equinox holds from 4.2 to 5.3 quarts of oil with a filter change.
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2020 AWD Chevy Equinox 2.0L LTG Turbo | 6 qt (5.7 l) | 5W-30, 0W-30 |
| 2020 FWD Chevy Equinox 2.0L LTG Turbo | 5 qt (4.7 l) | 5W-30, 0W-30 |
| 2020 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2020 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
2021 Chevy Equinox Engine Oil Capacity and oil type
The 1.5 Chevy Equinox holds 5.3 quarts for an AWD model and 4.2 quarts of oil for an FWD model.
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2021 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2021 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
2022 Chevy Equinox Engine Oil Capacity and oil type
The 1.5 Chevy Equinox holds 5.3 quarts for an AWD model and 4.2 quarts of oil for an FWD model.
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2022 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2022 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
2023 Chevy Equinox Engine Oil Capacity and oil type
The 1.5 Chevy Equinox holds 5.3 quarts for an AWD model and 4.2 quarts of oil for an FWD model.
| Engine type | Engine Oil Capacity with filter | Oil type |
| 2023 AWD Chevy Equinox 1.5L LYX Turbo | 5.3 qt (5 l) | 0W-20 |
| 2023 FWD Chevy Equinox 1.5L LYX Turbo | 4.2 qt (4 l) | 0W-20 |
Chevy Equinox 1.5 Engine Oil Capacity
The Chevy Equinox 1.5 Engine Oil Capacity is 5.3 quarts for AWD vehicles and 4.2 quarts for FWD vehicles. This is true for drain and refill.
| Engine Oil Capacity with filter | Oil type | Drain plug torque |
| AWD: 5.3 quarts FWD: 4.2 quarts | 0W-20 | 18 ft/lbs |
What Kind Of Oil Does A Chevy Equinox Take?
The 1.5 Chevy Equinox requires the 0W-20 synthetic oil.
How Many Quarts Of Oil Does A Chevy Equinox Take?
The 2022 Chevrolet Equinox with the 1.5L 4-cyl engine (engine code LYX Turbo) takes 5.3 quarts (with filter) of 0W-20 synthetic oil. The Chevy Equinox with a 2L 4-cyl engine (engine code LTG Turbo) takes 6 quarts (with filter) of 5W-30 synthetic oil. A new oil filter and a crush washer are required.
How Much Oil Does A Chevy Equinox Take?
The Chevy Equinox with a 1.5l engine takes 5.3 quarts (5 liters) of oil for an AWD vehicle and 4.2 quarts (4 liters) for an FWD vehicle.
How Often Does A Chevy Equinox Need An Oil Change?
An oil change is one of the most essential and time-consuming services for your automobile. For conventional oil, Chevrolet advises having your Chevy Equinox’s oil & filter changed every 3,000-5,000 miles. Synthetic oil should be changed at 7,500 to 10,000 miles if appropriate. Keep in mind that it’s preferable to consult your owner’s manual and dealer about the best intervals for your car.
Full Synthetic Oil Change
The highest quality motor oil for your car is a synthetic blend. It has the greatest level of protection. Synthetic motor oil is made from chemical compounds and formulations, allowing scientists to develop motor oil that in molecular terms offers more complete protection.
This implies that the improved viscosity index, greater resistance to oxidation thermal breakdown, and reduced sludge problems are just a few of the advantages you won’t find in traditional oils. Full synthetic motor oil ensures that your engine is as close to brand-new as feasible for as long as feasible, which adds up to higher road assurance.
What Is Synthetic-Blend Oil?
The easiest technique to ensure your engine is in excellent working order is to maintain up with your typical oil changes and other maintenance services as prescribed. Whether or not your engine is quiet, it’s clear that there’s a lot of combustion happening on the inside, so it’s important to keep everything lubricated at all times and synthetic-blend motor oil is becoming more popular as a result.
Your automobile’s engine is its beating heart. You should make certain that you look after it properly, much like your body. Synthetic blend motor oil incorporates the best features of conventional motor oil and complete synthetic oil.
